Measures

• O₂ 0-21% ppm
• CO 0-10,000ppm H₂compensated with over range protection - 100,000ppm / 10% option
• Option to measure 2 extra gases: NO to 5000ppm, NO2 to 1,000ppm & SO2 to 5,000ppm
• Differential temperature -20 to +135°C
• Differential pressure +/- 160mbar

Sensor options - up to 2

• NO 0-5,000ppm
• NO2 0-1,000ppm**
• SO2 0-5,000ppm**
• CO 0-10% replaces standard CO sensor*

Probe & Accessory Options

• CHSP5 285mm high temperature PTFE lined smoke probe with removeable shaft & 4m neoprene hose
• CHSLP5 1m high temperature PTFE lined smoke probe with removeable shaft & 4m neoprene hose
• KMCE10 10m hose & thermocouple extension
• KANE-GCU** Gas conditioning unit
• KANE-IRP3 Printer

KANE LINK Options

• KANE-WPCP2 Wireless LINK temp clamp probes - connect as a pair
• KANE-DTHA2 Wireless LINK airflow, temp & RH
• KANE79 Wireless LINK CO monitor to 999ppm - connect up to 4

Calculates

• CO₂
• CO/CO₂ ratio
• NOx (option)
• Excess air
• Combustion efficiency

Fuel Types

10 standard fuels including: - Natural Gas, LPG, Butane, Propane, Light Oil, Heavy Oil & user fuels
